Product Description
The mud tank agitator is widely used in the surface tank of drilling fluid. The function of the Xi'an HL mud tank agitator is to suspend all solid control particles uniformly, and the shearing action is appropriate, so that the performance of the entire drilling fluid system is consistent and power is saved.
Mud tank agitator features
1. Users require no coupling, which makes subsequent maintenance convenient and quick.
2. We shorten the transmission shaft distance, and this results in high transmission efficiency.
3. We shorten the transmission shaft distance, and this results in high transmission efficiency. (This appears to be a repeated point).
4. We install the shaft hole with matching, which greatly improves the concentricity.
5. It experiences normal wear, requires no wearing parts, and reduces labor intensity.
6. Compact structure, good meshing performance, reliable operation
>>Send an Enquiry sales@hlshiyou.com<<
Technical Parameters of Mud Tank Agitator
Model | HJB5.5 | HJB7.5 | HJB11 | HJB15 | HJB18.5 |
Motor Power（kW） | 5.5 | 7.5 | 11 | 15 | 18.5 |
Impeller Speed（rpm） | 57 | 57 | 58 | 58 | 58 |
Impeller Diameter（mm） | 800 | 850 | 900 | 1000 | 1200 |
Dimension: L×W×H（mm） | 954*549*583 | 1101*664*623 | 1222*664*665 | 1334*734*685 | 1465*888*770 |
Weight（kg） | 295 | 400 | 462 | 560 | 785 |
>>Send an Enquiry sales@hlshiyou.com<<
Most mud tank agitators are driven by motors. When used in oil field drilling, these motors have explosion-proof functions.
When trenchless or horizontal directional drilling, ordinary motors can be used to save costs.
