Product Description
HDD Mud Recycling System( is short for horizontal directional drilling) is applied to urban municipal construction and electrified pipe network transformation. Communication cable laying and the big and small rivers, lake and the horizontal directional crossing construction when the building cannot be demolished, especially in the environmental protection and municipal pipe network expansion project and the horizontal directional crossing construction of large pipeline crossing river project.
HL Petroleum supply mud recycling system for CBM & HDD & TMB and Piling that need drilling mud.
TDS
Parameters of HLMR HDD Mud Recycling System:
| System Capacity: | 200GPM (50m³/h) | 500GPM (120m³/h) | 1000GPM (240m³/h) |
| Particle Size after Treatment: | 15~44μm | 15~44μm | 15~44μm |
| Processing Stage: | two stages | three stages | three stages |
| Total System Power: | 44kW | 150kW | 184kW |
| Total System Volume: | 5m³ | 15m³ | 30m³ |
| External Dimensions of the System: | 4000x2360x2940mm | 10000×2360×4228mm | 12100×2630×4438mm |
>>Send an Enquiry sales@hlshiyou.com<<
Advantages
Technical Features of HLMR HDD Mud Recycling System:
Can effectively control drill fluids performance, reduce the drill-jamming accidents and improve pore-forming quality;
Can save bentonite and barite; drastically reduce the waste mud transportation cost;
The effective separation of soil slag by equipment will help to improve pore-forming efficiency;
The slurry closed cycle purification mode and lower slag moisture content reduce the impacts to the environment;
Safe and easy operation, simple maintenance, stable and reliable operation.
Reasonable design with compact structure and small footprint.
